NCC300OD (GQ-C5032WZ US) NG

The Undisputed Tankless Heavyweight

No matter your installation plans, the NCC300 is versatile enough to adapt with its small size, flexibility in venting material and termination location. The NCC300 is among the industry’s best 20:1 turn down ratio. It also features a wide BTU range of 15 to 300k.

Technical Literature

Technical Specs

Warranty

Heat Exchanger Warranty (w/out Recirculation) 5 Years
Heat Exchanger Warranty (w/Recirculation) 5 Years
Parts Warranty 5 Years
Labor Warranty 1 Year


For detailed warranty terms and conditions please refer to the Noritz warranty page
ENJJ020

Part #: ENJJ020

Inlet Power Wires

$6.97
ENUF010

Part #: ENUF010

Drain Hose

$9.77
ENUL004

Part #: ENUL004

Gasket - Exhaust (NCC300OD)

$34.86
ENWL005

Part #: ENWL005

Gasket - Junction Box Cover

$5.58
EPHF001

Part #: EPHF001

Drain Connection - Condensate

$55.79
EQNH001

Part #: EQNH001

Thermal Fuse (NCC300OD/DV)

$27.90
ETPA073

Part #: ETPA073

Inlet Power Wire Clip

$5.58
EULC022

Part #: EULC022

Mounting Plate - Ignition Plug

$5.58
EULL003

Part #: EULL003

Gasket - Ignition Plug

$6.97
EYDA016

Part #: EYDA016

Mounting Plate - Neutralizer / Condensate Container (NCC300OD/DV)

$6.97
EYDA017

Part #: EYDA017

Mounting Plate - Burner Case (NCC300OD/DV)

$27.90
EYDC086

Part #: EYDC086

Burner Damper 21-6 (NCC300OD-NG)

$111.57
EYDD001

Part #: EYDD001

Pipe - Water Inlet (NCC300OD/DV)

$111.57
EYDD021

Part #: EYDD021

Pipe - Secondary Heat Exchanger (NCC300OD/DV)

$83.68
EYDF006

Part #: EYDF006

Exhaust Top (NCC300OD)

$69.74
EYDJ013

Part #: EYDJ013

Wiring Harness - Gas Valve

$27.90
EYDJ016

Part #: EYDJ016

Wiring Harness - Manifold Plate

$69.74
EYDL002

Part #: EYDL002

Gasket - Burner (NCC300OD/DV)

$27.90
EYDL012

Part #: EYDL012

Gasket - Manifold Plate Top (NCC300OD/DV)

$6.97
EYDL015

Part #: EYDL015

Gasket - Fan Housing (NCC300OD/DV)

$13.95
EYLF041

Part #: EYLF041

Fan Plate (NCC300OD)

$9.77
EYPD012

Part #: EYPD012

Coupling - Inlet Water (SET) (NCC300OD/DV)

$153.42
EYPF035

Part #: EYPF035

Drain Hose - Condensate (NCC300OD/DV)

$9.77
EYQJ017

Part #: EYQJ017

Wiring Harness - Power Switch (NCC300OD/DV)

$20.92
FABH001

Part #: FABH001

High Limit Switch - 194

$13.95
FAQJ033

Part #: FAQJ033

Power Switch (NCC300OD/DV)

$27.90
JBGH003

Part #: JBGH003

Freeze Prevention Heater (NCC300OD/DV)

$13.95
SAA6483-B

Part #: SAA6483-B

O-Ring - High Temp 4C

$6.97
SAB1512-B

Part #: SAB1512-B

O-Ring - Gas Pipe P25.5

$5.58
SAB4190

Part #: SAB4190

O-Ring - Water Filter

$9.77
