NCC199CDV (GQ-C3259WZ-FF US) LP

NCC199CDV Commercial Tankless Water Heater

The NCC199CDV commercial condensing tankless water heater from Noritz has a thermal efficiency of 98% and is CSA-approved for common venting up to six units. With a maximum input of 199,900 BTUs per hour (BTU/hr), the NCC199CDV features two austenite 316L stainless steel heat exchangers that resist corrosion from condensate and chloride, maximizing durability and lifespan.

Technical Literature

Technical Specs

Warranty

Heat Exchanger Warranty (w/out Recirculation) 10 Years
Heat Exchanger Warranty (w/Recirculation) 10 Years
Parts Warranty 5 Years
Labor Warranty 1 Year


For detailed warranty terms and conditions please refer to the Noritz warranty page
1323709-B

Part #: 1323709-B

O-Ring - Thermistor High Temp P4 (replaced 1323709)

$6.97
2110903

Part #: 2110903

O-Ring - Gas P18

$5.58
2192004

Part #: 2192004

O-Ring - P20

$5.58
3223302-B

Part #: 3223302-B

O-Ring - High Temp P16 (replaced 3223302)

$5.58
3264408

Part #: 3264408

O-Ring - High Temp P6

$5.58
6340300-B

Part #: 6340300-B

C Clamp - Water Pipe 16A (Replaced 6340300)

$5.58
6340407

Part #: 6340407

C Clamp - Gas Pipe 16B

$5.58
ALSD088-B

Part #: ALSD088-B

Thermistor Holding Plate (replaced ALSD088)

$6.97
ALSJ078

Part #: ALSJ078

High Voltage Igniter Wire L175

$6.97
ALSJ084

Part #: ALSJ084

High Voltage Igniter Wire L220

$6.97
AMML001

Part #: AMML001

Clamp -Freeze Prevention

$5.58
BWCD093-B

Part #: BWCD093-B

Magnetic Sensor - Flow Sensor (Replaced BWCD093)

$41.84
BWCD096

Part #: BWCD096

Thermistor - Hot Water

$27.90
BWCD097-B

Part #: BWCD097-B

Thermistor - Cold Water (replaced BWCD097)

$27.90
BWCD098-B

Part #: BWCD098-B

Thermistor -Heat Exchanger (replaced BWCD098)

$27.90
BWCH003

Part #: BWCH003

Thermistor - Air

$27.90
CBND018

Part #: CBND018

Drain Connection - 1/4in tube

$6.97
CRPJ014-B

Part #: CRPJ014-B

LED Light (replaced CRPJ014)

$13.95
CRUD003-B

Part #: CRUD003-B

Drain Cock (Replaced CRUD003)

$5.58
CRUD055

Part #: CRUD055

C Clamp - Thermistor

$5.58
CVAL004

Part #: CVAL004

Gasket - Front Cover Sides

$5.58
CXPA026-B

Part #: CXPA026-B

Wire Grommet - Rubber

$5.58
DNSA025

Part #: DNSA025

Cover - External Remote Terminal Block

$6.97
Out of Stock
DNSA026

Part #: DNSA026

External Remote Terminal Block

$34.86
DTJD006

Part #: DTJD006

Water Filter Cap

$6.97
DYTD002

Part #: DYTD002

Water Connector - Elbow

$13.95
EBTD023

Part #: EBTD023

Wire Cover - Servo

$5.58
EGBD032

Part #: EGBD032

Water Filter (replaced DTJD005)

$13.95
ELVE021

Part #: ELVE021

Inlet Gas Connection w/ Screw (SET)

$27.90
ELVK003

Part #: ELVK003

Label - Outside Front Cover Caution Label

$13.95
