NCC199-DV-LP

NCC199DV Commercial Condensing Water Heater

The NCC199DV commercial tankless features a gas range of 16,000 BTUh to 199,900 BTUh. It also features a maximum flow rate of 11.1 GPM, durable stainless steel casing, 94% efficiency, temperature controls, and multi-system capability.

Technical Literature

Technical Specs

Warranty

Heat Exchanger Warranty (w/out Recirculation) 5 Years
Heat Exchanger Warranty (w/Recirculation) 5 Years
Parts Warranty 5 Years
Labor Warranty 1 Year


For detailed warranty terms and conditions please refer to the Noritz warranty page
SAA2811-B

Part #: SAA2811-B

Safety Relief Valve

$27.90
SAA6044-B

Part #: SAA6044-B

O-Ring - Gas Solenoid

$6.97
SAB2753

Part #: SAB2753

Screw SET (DISCONTINUED - replaced with SAF6007)

DISCONTINUED - replaced with SAF6007
View Parts
SAD6531

Part #: SAD6531

Clamp - Condensate Hose NO.39

$5.58
SAD6593

Part #: SAD6593

C Clamp - Water Pipe 16-25

$5.58
SAD6594

Part #: sad6594

C Clamp - 1/4in tube 6-13

$5.58
SAD6633-B

Part #: SAD6633-B

O-Ring - High Temp P3

$2.79
SAD6635-B

Part #: SAD6635-B

O-Ring - High Temp P9

$2.79
SAE6198

Part #: SAE6198

Cord bushing SR-5P-4 (Replaced with ETPA073)

Replaced with ETPA073
View Parts
SBH9490

Part #: SBH9490

Water Servo - Bypass (SET) (replaced DZTD010)

$111.57
SBH9491

Part #: SBH9491

Water Servo -Main (SET) (replaced DZTD011)

$111.57
SHB7032

Part #: SHB7032

Circuit Board

DISCONTINUED - replaced with SKH7357
View Parts
SKC7447

Part #: SKC7447

Burner w/ Gasket and Ignition Plug (SET)

$230.12
SKC7448

Part #: SKC7448

Ignition Plug w/ Gasket

$27.90
SKC7449

Part #: SKC7449

Flame Rod Plug w/ Gasket

$13.95
SKC7453

Part #: SKC7453

Thermal Fuse - Multiple Units

$13.95
SKC7454

Part #: SKC7454

Freeze Prevention Heater - Double Round (SET)

$27.90
SKD7441

Part #: SKD7441

Fan Motor w/ Housing - Multiple Units

$167.37
SKD7466

Part #: SKD7466

Neutralizer Container (SET)

$83.68
SKD7467

Part #: SKD7467

Gasket - Exhaust Flue

$62.76
SKD7469

Part #: SKD7469

O-Ring - Exhaust Flue Φ100

$41.84
SKF7380

Part #: SKF7380

Gas Valve w/ Manifold Plate 23 (SET)

$278.94
SKG7021

Part #: SKG7021

Heat Exchanger Kit - (NCC199 & NRC111) Primary CU (SET)

$725.23
SKG7022

Part #: SKG7022

Heat Exchanger Kit - (NCC199 & NRC111) Secondary SS (SET)

$725.23
SKG7767

Part #: SKG7767

Pipe - 1/4in Drain from CU Heat Exchanger (SET) (SS)

$104.60
SKH7357

Part #: SKH7357

Circuit Board - NRC111,NCC199

$390.51
SKJ726X

Part #: SKJ726X

Transformer

$104.60
